2007 KOMATSU PC300-8

Sale Price: $126,500 Watch Price Make An Offer
$
For security reasons, do not select "Remember my details" if you are using a shared computer.
View our privacy policy, collection notice and terms and conditions to understand how we use your personal information.
Report Listing

Contact Seller

Phone: 08 6500 0998

Email Advertiser:

For security reasons, do not select "Remember my details" if you are using a shared computer.
View our privacy policy, collection notice and terms and conditions to understand how we use your personal information.

Dealer

Brooks Equipment Sales Pty Ltd

30 Coulson Way

Canning Vale, WA

Brooks Equipment Sales Pty Ltd Visit website

Features

Title 2007 KOMATSU PC300-8
Type Excavators
Sub Type Excavators
Class 20-45 tonnes
Make KOMATSU
Model PC300-8
Year 2007
Sale Price $126,500
Listing Type Used
Stock Number EX046
RefCode TA1205899
CategoryTrack Mounted
Hours10440

Description

LOCATED IN CANNING VALE, WA.
$115,000 +GST

The PC300-8M0 incorporates a holistic, integrated design with a host of standard factory installed items to provide piece of mind and compliance with industry expectations.  It combines Dash 8 quality and performance with new fuel saving technology to further improve fuel efficiency, upgraded monitor / KOMTRAX functionality and high capacity air conditioning with increased cool down performance.

This 33+ tonne excavator includes the latest technology, ergonomics and features.  It is suited to large construction jobs requiring a combination of heavy lift, wide working range and high productivity.

Highly productive cycle times are achieved through optimum weight and power balance.



Download Specification Brochure



EQUIPMENT DETAILS
Year 2007
Make Komatsu
Model PC300



Performance
Operating Weight  33800kg
Swing speed 9.5 rpm
Bucket digging force (ISO)  23200 kgf
Arm crowd force (ISO) 17400 kgf
Digging depth maximum 7380 mm
Digging reach maximum 11100 mm
Maximum reach @ ground level 10920 mm
Horsepower, Gross SAE  194 kW
Horsepower, Net ISO 187 kW
Horsepower, Net SAE 1950 kW
Rated RPM 1950
Fan drive method Mechanical
Displacement (litre) 8.27
Number of cylinders 6

Dimensions
A Overall length 11150 mm
B Length on ground (transport) 5755 mm
C Overall height (to top of boom) 3285 mm
D Overall width 3190 mm
E Overall height (to top of cab) 3145 mm
F Ground clearance, counterweight 1185 mm
G Ground clearance (minimum)   500 mm
H Tail swing radius   3450 mm
I Track length on ground     3700 mm
J Track length 4625 mm
K Track gauge   2590 mm
L Width of crawler   3190 mm
M Shoe width   600 mm
N Grouser height   36 mm
O Machine cab height   2585 mm
P Machine cab width   3090 mm
Q Distance, swing center to rear end 3405 mm

Working Range
A Max. digging height 10100 mm
B Max. dumping height     7050 mm
C Max. digging depth     7380 mm
D Max. vertical wall digging depth   6400 mm
E Max. digging depth of cut for 8 level       7180 mm
F Max. digging reach   11100 mm
G Max. digging reach at ground level 10920 mm
H Min. swing radius   4430 mm
